High pressure Water Hose Reels Z-series (Heavy Duty)
- Hose reels with a high pressure water hose.
- Heavy duty single arm reel made with heavy gauge steel.
- Product
- Z-series High pressure Water Hose Reel 9.5mm X 15.0M
- Model
- ZLO-315
- Features
-
- Single arm heavy duty reel for industrial applications.
- Reels come with Inlet hose.
- Guide arms adjust to wall, floor and overhead positions.
 |
Z-series High pressure Water Hose Reel Model：ZLO-320 |
||
|
Z-series High pressure Water Hose Reel Model：ZLO-410 |
|
Z-series High pressure Water Hose Reel Model：ZLO-415 |
 |
Light Gray ＊ Special order only |
 |
Orange ＊ Special order only |
- Product
- Z-series High pressure Water Hose Reel 9.5 X 8.0M
- Model
- ZSO-308
- Features
-
- Single arm heavy duty reel for industrial applications.
- Reels come with Inlet hose.
- Guide arms adjust to wall, floor and overhead positions.
|
Light Gray ＊ Special order only |
|
Orange ＊ Special order only |
Specifications
| Model | Hose | Maximum Working Pressure (MPa) |
Inlet Hose | Dimensions (mm) |
Body Weight (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hose materials |
Connection | Inner Diameter (mm) |
Length (m) |
Connection | Length (m) |
A | B | C | |||
| ZLO-315 | 1 braid | Female R 3/8 |
9.5 | 15.0 | 7.0 | Female R 3/8 |
1.0 | 540 | 516 | 205 | 26.0 |
| ZLO-320 | 1 braid | Female R 3/8 |
9.5 | 20.0 | 7.0 | Female R 3/8 |
1.0 | 540 | 516 | 205 | 28.3 |
| ZLO-410 | 1 braid | Female R 1/2 |
12.7 | 10.0 | 7.0 | Female R 1/2 |
1.0 | 540 | 516 | 205 | 25.4 |
| ZLO-415 | 1 braid | Female R 1/2 |
12.7 | 15.0 | 7.0 | Female R 1/2 |
1.0 | 540 | 516 | 205 | 27.6 |
| Model | Hose | Maximum Working Pressure (MPa) |
Inlet Hose | Dimensions (mm) |
Body Weight (kg) |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hose materials |
Connection | Inner Diameter (mm) |
Length (m) |
Connection | Length (m) |
A | B | C | |||
| ZSO-308 | 1 braid | Female R 3/8 |
9.5 | 8.0 | 7.0 | Female R 3/8 |
1.0 | 392 | 380 | 202 | 18.0 |
Installation Positioning |
Dimensions |
 |
 |
Notes:
• Read the manual thoroughly and use it properly.
• The actual product color may differ.
• Product specifications are subject to change for improvements without notice.
• These products are for indoor use only.
